ZJ Beny DC Mini Circuit Breaker 600V 20A

ZJ Beny DC Mini Circuit Breaker 600V 20A

$39.99 CAD
$69.99 CAD $39.99 CAD
Sale Sold out
Shipping calculated at checkout.
  • Non-polarity
  • High Short-Circuit / Breaking Capacity
  • Overload, Short Circuit, Unfrequent Operation and Anti-reflux Protection
  • p to 600V 20A
  • Comply with: UL 489B
  • Breaking Capacity: 5kA
View full details



  • Description
  • Applications
  • Specifications
  • Datasheet
  • Reviews

ZJ BENY BDM series PV DC miniature circuit breakers (MCB) can be used in solar DC circuits up to 600VDC. Applications in solar DC Circuits, battery energy storage & UPS. ARC flash barrier design keeps solar equipment safe & reliable. For DC circuit over-current protection.

Features:

  • All sides IP40, Connection Terminal IP20
  • AS60947.2 and IEC 60947-2 standard
  • Protection functions; Overload, short circuit, unfrequented operation
  • High short circuit / breaking capacity
  • Rated voltage up to 600V DC
  • Tested to extreme conditions -40 - +70 degrees Celsius
  • A range of current sizes available
  • Marine
  • RV's
  • Caravans
  • Off-Grid Systems
  • Tiny Houses
  • Cabins

Download Datasheet (PDF)

Electrical Characteristics Details
Type BBI-63
Comply with UL 489B
Pole 2P
Rated Working Voltage (Ue) 600V DC
Conventional thermal current (Ith) 50A
Rated Current (In) 6A, 10A, 13A, 16A, 20A, 25A, 32A, 40A, 50A
Rated Insulated Voltage (Ui) 1200V DC
Rated Impulsed Voltage (Uimp) 6kV
Ultimate Breaking Capacity (Ics) 5kA
Tripping Type Thermal Magnetic Type
