SR-IU series High-Frequency Pure Sine Wave Inverter SR-IU12-1kW SR-IU12-2kW SR-IU12-3kW

SR-IU series High-Frequency Pure Sine Wave Inverter SR-IU12-1kW SR-IU12-2kW SR-IU12-3kW

$499.99 CAD
$699.99 CAD $499.99 CAD
Vente Épuisé
Frais d'expédition calculés à l'étape de paiement.

SR-IU12 Series Inverter Summary

Key Specifications

Power Ratings
  • 1kW: 1,000W (2,000W peak)
  • 2kW: 2,000W (4,000W peak)
  • 3kW: 3,000W (6,000W peak)
Electrical Characteristics
  • Output: 110-120Vac ±3%
  • Waveform: Pure sine wave
  • Efficiency: 87.5%-94.5%
Physical Specs
  • 1kW Size: 331×228×88mm (3.2kg)
  • 2kW Size: 406×300×116mm (5.3kg)
  • Cooling: Natural + forced air

Model Comparison

Feature 1kW 2kW 3kW
Battery Voltage 12V - -
Max Efficiency 91.5% 92% 91.5%
Standby Power <0.26A <0.24A <0.24A

Technical Highlights

  • Pure sine wave output (THD <4%)
  • Wide operating temp: -20°C to 60°C
  • Dual cooling system
  • Certifications: CE, ROHS, IEC62109

IP20 protection, 50/60Hz supported

Shipping

Free
Local Shipping

Warranty

30-year Hassle Free
Warranty

Support

Lifetime Customer
Support
Afficher tous les détails
  • Advanced SPWM modulation technology with pure sine wave output and high power quality.
  • High power density and long life devices are selected to support long term operation at full power.
  • High conversion efficiency, low losses and low harmonic distortion rate.
  • Multiple operating modes for maximum power savings.
  • Bluetooth as standard, supports mobile phone app to view device operating parameters.
  • Multiple expansion interfaces to meet the diverse needs of users.
  • With battery over-voltage and over-discharge protection, output overload and short-circuit protection and over-temperature protection.(there is no reverse connection protection, please do not reverse the connection）
  • Surge protection design is suitable for lithium battery power systems.
